Pipe & Tubes

Complete range of seamless and welded pipes & tubes in stainless steel, carbon steel, alloy steel, nickel alloys, and non-ferrous metals.

1 result

Stainless Steel Pipe & Tubes

Manufacturer, Supplier & Stockist

Swastik Metal Industries is one of the leading manufacturers, suppliers and stockists of Pipe & Tubes in India. Complete range of seamless and welded pipes & tubes in stainless steel, carbon steel, alloy steel, nickel alloys, and non-ferrous metals.

Swastik Metal Industries is a leading stockist and supplier of seamless and welded pipes & tubes in stainless steel, carbon steel, alloy steel, nickel alloys, and non-ferrous metals. Our comprehensive inventory includes round, square, and rectangular tubes ranging from 1/2" to 24" NB in wall thicknesses from Sch. 5S to Sch. XXS. We cater to industries including oil & gas, petrochemical, chemical processing, power generation, and food & beverage with ASTM A312, A53, A106, A335 grade pipes. Every pipe leaving our facility undergoes rigorous quality inspection to ensure dimensional accuracy and material integrity.

ISO 9001:2015 Certified

Pan-India Delivery

Material Test Certificates

Call: +91 76660 05007

Specifications & Grades

Stainless SteelASTM A312 TP 202/304/304L/304H/316/316L/317/317L/321/310/347/904L

Carbon SteelASTM A53 GR.B / A106 GR.B / API 5L GR.X42/46/52/56/60/65/70

Low Temp Carbon SteelA333 Gr.3 / Gr.6

Alloy SteelASTM A335 GR. P1/P5/P9/P11/P22/P91

Nickel AlloysMonel, Nickel, Inconel, Hastelloy, Titanium, Tantalum, Bismuth, Aluminium, High Speed Steel, 904L, Alloy 20

Non FerrousCopper, Aluminium, Brass, Bronze, Zinc, Lead

TypesRound, Square, Rectangular

Size1/2" to 24" NB (Seamless & Welded)

Wall ThicknessSch. 5S to Sch. XXS

Interested in Pipe & Tubes?

Send us your requirements and we'll provide the best quote within 24 hours.

Dimensional Specification Tables3 tables

C.S./A.S./S.S. Pipe & Tubes Schedule Dimensions, Wall Thickness, Wt./mtr. (kg)

Size (inch)	O.D. (mm)	5S mm	5S kg/m	10S mm	10S kg/m	10 mm	10 kg/m	20 mm	20 kg/m	30 mm	30 kg/m	40 mm	40 kg/m	Std mm	Std kg/m	XS mm	XS kg/m	D. Tube Size P.
1/8"	10.3	—	—	1.28	0.28	—	—	1.60	0.345	—	—	1.78	0.36	1.73	0.36	2.41	0.46	1/8"
1/4"	13.7	—	—	1.65	0.49	—	—	2.00	0.580	—	—	2.24	0.63	2.24	0.63	3.02	0.80	1/4"
3/8"	17.1	—	—	1.65	0.63	—	—	2.00	0.750	—	—	2.31	0.85	2.31	0.85	3.20	1.10	3/8"
1/2"	21.3	1.65	0.80	2.11	1.00	—	—	2.0	0.957	—	—	2.77	1.26	2.77	1.26	3.73	1.62	1/2"
3/4"	26.7	1.65	1.03	2.11	1.28	—	—	2.5	1.500	—	—	2.87	1.68	2.87	1.68	3.91	2.19	3/4"

Mild Steel Pipes Confirming to IS:1239 (Part-1)

Nominal Bore (inch)	Nominal Bore (mm)	Outside Diameter (in)	Outside Diameter (mm)	Light Thickness (mm)	Light Weight (kg/mtr)	Medium Thickness (mm)	Medium Weight (kg/mtr)	Heavy Thickness (mm)	Heavy Weight (kg/mtr)
1/8"	3 mm	0.406	10.32	1.80	0.361	2.00	0.407	2.65	0.493
1/4"	6 mm	0532	13.49	1.80	0.517	2.35	0.650	2.90	0.769
3/8"	10 mm	0.872	17.10	1.80	0674	2.35	0.852	2.90	1.02
1/2"	15 mm	0.844	21.43	2.00	0.952	2.65	1.122	3.25	1.45
3/4"	20 mm	1.094	27.20	2.35	1.410	2.65	1.580	3.25	1.90

Big Diameter ERW Pipes Confirming to IS 3589 Grade 410

Wall Thickness (mm)	7" NB / 193.7mm OD (kg/mtr)	8" NB / 219.1mm OD (kg/mtr)	10" NB / 273mm OD (kg/mtr)	12" NB / 323.7mm OD (kg/mtr)	14" NB / 355.6mm OD (kg/mtr)	16" NB / 406.4mm OD (kg/mtr)	18" NB / 457mm OD (kg/mtr)	20" NB / 508mm OD (kg/mtr)
4.85	22.59	25.62	32.07	38.13	-	-	-	-
5.20	24.17	27.43	34.34	40.85	-	-	-	-
5.60	26.00	29.28	36.93	43.93	48.11	-	-	-
6.00	27.88	31.53	39.50	47.02	51.49	51.00	69.00	-
6.35	29.34	33.28	41.73	49.67	54.43	62.35	70.50	78.50
